Precision foaming sealing equipment, temperature-resistant, durable, and exceptionally accurate, easily completes sealing processing for miniature components, supports customization to meet multi-country production needs.
Product Details
The WINMAN WM403-1 is a high-precision, compact FIPFG (Film Forming In-Situ Gasket) foaming machine based on German technology, designed to provide reliable sealing solutions for small instruments, home appliances, and microelectronic components. This equipment features ±0.01% ultra-precision coating control, achieving IP67 waterproof and dustproof performance. Intelligent path recognition and a dynamic AB component mixing system ensure consistent sealing. It boasts a maximum coating speed of 200mm/s, reduces energy consumption by 50%, and its core components can operate stably for over 20 years in extreme environments ranging from -15°C to +45°C. It supports unlimited path storage, high-pressure water cleaning (up to 500 meters per cycle), and remote maintenance (Wi-Fi/Ethernet), meeting the stringent requirements of European, Middle Eastern, and Asian customers for automation, low maintenance costs, and consistent quality. Manufactured by WINMAN INDUSTRIAL it is ISO9001 and CE certified and offers OEM/ODM customization options such as voltage configuration, dual-station design, and fixture adaptation.
Customized price reference
Payment method
COMM
Means of transaction
Core Functions and Advantages
Precision Dispensing
Dispensing accuracy of ±0.01% for precise sealing of small parts;
High-Efficiency Foaming
Adjustable foaming speed from 0 to 200 mm/s, improving efficiency by 50%;
Energy Saving and Consumption Reduction
Total machine power of 4 kW, reducing energy consumption by 50% compared with similar models;
Stable and Durable
Core components service life exceeds 20 years, suitable for a wide temperature range of -15°C to 45°C;
Sealing Protection
Sealing gasket reaches IP67 and passes a 15-atmosphere airtightness test;
Adjustable Ratio
AB material mixing ratio adjustable from 1:1 to 10:1, with ±1% accuracy;
Path Storage
Unlimited path storage supports multi-product production;
High-Pressure Water Cleaning
Single-operation coverage of up to 500 meters.
Process Flow
Product Loading and Positioning
Place the small-sized product into a compact fixture table for positioning and secure fixation.
Intelligent Path Recognition
The system automatically identifies the sealing path to ensure accurate processing.
Mixing and Foam Dispensing
Component A and Component B materials are dynamically mixed for precise dispensing and foaming.
One-Piece Molding, No Trimming Required
The sealing gasket is formed in one pass to the final shape, with no manual trimming required after molding.
Application Industries
Micro Instrument Manufacturing
Instrument sealing and environmental protection
Small Appliance Manufacturing
Complete product sealing with moisture and dust protection
Micro Waterproof Box Processing
Enclosure sealing and waterproof protection
Small Sheet Metal Parts Manufacturing
Structural sealing and protection treatment
Micro Electronic Component Encapsulation
Component encapsulation with moisture protection
Technical Parameters
| Parameter Category | Parameter Name | Parameter Value |
|---|---|---|
| Core Equipment | Model | WM403-1 |
| Working Accuracy | ±0.01% | |
| Foaming Speed | 0-200mm/s (adjustable) | |
| Control System | Germany Sonderhoff + PLC programmable control | |
| Applicable Materials | Two-component polyurethane (PU) foaming materials | |
| Feeding Ratio | A/B Ratio | 1:1-10:1 (adjustable), accuracy ±1% |
| Mixing Method | Dynamic high-speed mixing | |
| Core Components | German BARMAG metering pump, ABB/Siemens modules | |
| Operating Temperature | -15℃-45℃ | |
| Operation & Control | Operating Method | Touchscreen + robot teach pendant programming |
| Worktable Surface | Portable customized tooling table | |
| Data Storage | Unlimited path storage | |
| Cleaning System | High-pressure water cleaning + high-pressure air blow drying | |
| General Parameters | Operating Voltage | 380V/220V optional |
| Total Machine Power | 4KW | |
| Protection Rating | Equipment IP54, sealing strip IP67 | |
| Communication Functions | WiFi + Ethernet, supports remote operation & maintenance | |
| Equipment Features | Equipment Features | Portable, supports mobile operation |
Customer Cases
Kuwait’s Low-Voltage Electrical Manufacturing Industry Introduces the WM-601 Automatic Foaming Sealant Coating Machine to Achieve Dual Improvements in Efficiency and Quality
WINMAN INDUSTRIAL deployed the WM-601 FIPFG automatic foaming dispensing machine for a leading low-voltage electrical manufacturer in Kuwait, helping resolve material buildup and pipeline blockage issues found in semi-automatic equipment. With dynamic mixing, dual-core system control, and remote maintenance support, the project improved production efficiency, raised product consistency, and reduced operating costs in a high-standard electrical sealing application.
Check the details
Schneider Electric Cabinet Sealing Upgrade with WM601 FIPFG Dispensing Solution
WINMAN INDUSTRIAL delivered a customized WM601 FIPFG dispensing solution for Schneider Electric’s low- and medium-voltage cabinet manufacturing, helping upgrade a semi-automatic sealing process with more stable material control, better gasket consistency, and higher protection performance. The project addressed clogging, production instability, and quality variation while improving efficiency, reducing defects, and lowering overall operating cost.
Check the details
UAE Dubai intelligent electrical customer introduced the WM601 FIPFG sealing dispensing solution, efficiency increased by 60%
WINMAN Industrial provided a customized WM601 FIPFG in-situ foaming sealing solution for a smart electrical and new energy customer in Dubai facing sealing instability, material clogging, and maintenance issues in high- and low-voltage cabinet production. The project helped improve production efficiency, reduce defects, and support more consistent outdoor electrical equipment sealing with remote maintenance and on-site programming support.
Check the details
TESLA Door Module Panel FIPFG Foamed Sealing: WM601 Two-Component PU Fully Automatic Dispensing Achieves a 60% Increase in Mass Production Efficiency
WINMAN INDUSTRIAL delivered a WM601 fully automatic two-component PU FIPFG sealing solution for Tesla’s vehicle control cabinet and door panel sealing application. The project addressed material buildup, clogged pipelines, and unstable semi-automatic production by introducing dynamic mixing, online metering, precise trajectory dispensing, and process control, helping improve line efficiency, reduce defects, and support more stable mass production.
Check the detailsCompany Profile
