Why FIPFG Equipment Requires More Than Hardware
WM-601 FIPFG Automatic Foaming Machine
Reliable FIPFG Sealing Depends on More Than Hardware
For battery pack sealing, energy storage cabinets and other high-protection industrial applications, a machine is only one part of the production system. Consistent sealing results also depend on process testing, material and parameter matching, installation commissioning and operator training. Shanghai Winman Industrial Co., Ltd. supports these connected stages around the WM-601 FIPFG automatic foaming machine to help customers establish a repeatable and practical sealing process.
Why Process Integration Matters in FIPFG Applications
FIPFG, or Formed-In-Place Foam Gasket, creates a foamed sealing gasket directly on the workpiece. The final result is influenced by more than the equipment itself. Foam behavior, substrate condition, dispensing path, line speed, curing conditions and production handling all need to work together.
Process Testing
Testing helps assess the selected sealing process and provides a basis for adjusting application parameters before production integration.
Parameter Matching
Material characteristics, coating speed, dispensing path and workpiece requirements must be coordinated to support stable gasket formation.
Commissioning and Training
Correct installation, parameter setup and operator training help production teams use the equipment consistently and efficiently.
What the WM-601 Supports
The WM-601 is designed for demanding sealing applications such as新能源汽车电池包 and energy storage cabinets. Based on German-origin FIPFG technology, the machine combines automated dispensing, programmable movement and process-oriented equipment functions to support the integration of sealing into industrial production lines.
- Coating accuracy up to ±0.05 mm for controlled gasket application and sealing consistency.
- Adjustable operating speed from 0 to 300 mm/s to accommodate different process requirements.
- Dual-station automatic operation to support higher equipment utilization and reduce manual workload.
- Programmable dispensing paths for repeatable application on defined workpiece geometries.
- Optional plasma surface treatment and customized voltage configurations for project-specific integration needs.
- Remote diagnosis and maintenance functions to support equipment service and technical response.
A Structured Path from Testing to Production
| Stage | Purpose |
|---|---|
| 1. Process testing | Review the workpiece, sealing requirements and application conditions to define a suitable testing direction. |
| 2. Parameter matching | Coordinate dispensing speed, movement path and related process settings with the selected FIPFG application. |
| 3. Installation commissioning | Check equipment integration, operating functions and production readiness at the customer’s site. |
| 4. Operator training | Help operators understand machine operation, path programming, routine cleaning and basic maintenance requirements. |
Designed for Demanding Sealing Environments
The WM-601 is intended for applications where sealing consistency and protection against moisture or environmental exposure are important. When the equipment, materials and process parameters are properly matched and validated, the system can support sealing requirements associated with battery packs, energy storage cabinets and other industrial enclosures.
Operational Features That Support Production
- A German Sonderhoff control system is used to support equipment control and long-term operation.
- The high-pressure water and air cleaning system simplifies cleaning and helps reduce the need for manual edge trimming.
- Remote maintenance capability can assist with technical troubleshooting and service coordination.
- Energy consumption can be as low as 3.5 kW, depending on the equipment configuration and operating conditions.
- The system is designed in accordance with ISO9001 and CE-related requirements stated for the product.
Process reliability is built through coordination. For the WM-601, testing, parameter matching, commissioning and operator training form an important part of equipment delivery—not an optional step after the machine is installed.
With experience in FIPFG equipment development and industrial sealing applications, Shanghai Winman Industrial Co., Ltd. provides technical support for customers in Europe, the Middle East, Asia and other markets. For a WM-601 project, the appropriate process approach should be determined according to the workpiece design, sealing material, production requirements and equipment integration conditions.
